DIN 6798 A Serrated Lock Washer • Spring Steel • Stainless Steel
Size
Material Type
Coating
Description
DIN 6798 A Serrated Lock Washer • Spring Steel • Stainless Steel Material: Stainless Steel, Spring Steel Finishing: Electrolytic Plating (Zn, ZnNi), Phosphating (Fe, Zn, Mn) Sales Models: Wholesale Min. Order: 1000 pcs
| d1 | 1,7 | 2,2 | 2,7 | 3,2 | 3,7 | 4,3 | 5,3 | 6,4 | 7,4 | 8,4 |
| d2 | 3,6 | 4,5 | 5,5 | 6 | 7 | 8 | 10 | 11 | 12,5 | 15 |
| Uygun Diş Çapı For Thread Size | 1,6 | 2 | 2,5 | 3 | 3,5 | 4 | 5 | 6 | 7 | 8 |
| d1 | 10,5 | 13 | 15 | 17 | 19 | 21 | 23 | 25 | 28 | 31 |
| d2 | 18 | 20,5 | 24 | 26 | 30 | 33 | 36 | 38 | 44 | 48 |
| Uygun Diş Çapı For Thread Size | 10 | 12 | 14 | 16 | 18 | 20 | 22 | 24 | 27 | 30 |
