DIN 940 Stud
Size
Description
DIN 940 Stud
| d | M 4 | M 5 | M 6 | M 7 | M 8 (8x1) | M 10 (10x1,25) | M 12 (12x1,25) |
| b (l ≤ 125) | 14 | 16 | 18 | 20 | 22 | 26 | 30 |
| b (125 < l ≤ 200) | 20 | 22 | 24 | 26 | 28 | 32 | 36 |
| b (l > 200) | _ | _ | _ | _ | _ | 45 | 49 |
| e | 10 | 13 | 15 | 18 | 20 | 25 | 30 |
| l | 20-40 | 22-50 | 25-60 | 28-70 | 30-80 | 35-100 | 40-120 |
| d | M 14 (14x1,5) | M 16 (16x1,5) | M 18 (18x1,5) | M 20 (20x1,5) | M 22 (22x1,5) | M 24 (24x2) |
| b (l ≤ 125) | 34 | 38 | 42 | 46 | 50 | 54 |
b | 40 | 44 | 48 | 52 | 56 | 60 |
| b (l > 200) | 53 | 57 | 61 | 65 | 69 | 73 |
| e | 35 | 40 | 45 | 50 | 55 | 60 |
| l | 45-140 | 50-160 | 55-180 | 60-200 | 65-200 | 70-200 |
